Cal-Royal · Hinges
CR3D81
Model CR3D81
Project pricing by quote
Finish — Satin Brass
5 ⅛" x 1 ³⁄₁₆" (130 x 30 mm)
View manufacturer productFeatures & options
- Zinc Alloy manufactured for Oxidation Resistance
- Durable Galvanized Steel Covers to conceal the screws
- Used for wood and hollow metal doors
- 100% Made in Italy
- Elegant minimalistic design that is available inUS1, US4, US10B, US14, US15, US26, US26D and US28 finishes with no visible screws
- Main Features
- Easy 3D adjusting system
- Easy installation and maintenance free
- Complete reversibility (same slot on the door and the frame)
- Total recessed hinge body (door and frame gap is very small)
- Internal milling up to ⅜” (10mm) from the edge
- European Standard EN1634-1 for 60-Minute Fire Doors
- CE Certified for 200,000 Opening / Closing Cycles
- 5 Year Warranty
Specifications
- Dimensions
- 5 ⅛” x 1 3/16”
Product documents
SpecificationsCR3D81 specificationsAccessories3D Hinge Accessories 2025CR3D81_Template & Instruction SheetCR3D81 Instruction Sheet webDrilling Template for 3D Hinges_Instruction SheetDrilling Template for 3D Hinges - Instruction Sheet v2Part Numbers3D Invisible Hinges Part Numbers 2025View Catalog3D Invisible Hinges Catalog 2025Handing Chartdoorframehandingchart
