Manufacturer product view. Confirm the selected finish on your quote.
Cal-Royal · Hinges
CR3D62
Model CR3D62
Project pricing by quote
Finish — Satin Brass
6 ⁵⁄₁₆" x 1 ¼" (160 x 32 mm)
View manufacturer productFeatures & options
- Zinc Alloy manufactured for oxidation resistance
- Durable galvanized steel covers to conceal the screws
- Used for wood and hollow metal doors
- 100% Made in Italy
- Elegant minimalistic design that is available in US1, US4, US10B, US14, US15, US26, US26D and US28 finishes with no visible screws
- Main Features
- Easy 3D adjusting system
- Easy installation and maintenance free
- Complete reversibility (same slot on the door and the frame)
- Total recessed hinge body (door and frame gap is very small)
- Milling cut up to ⁹⁄₃₂” (7mm) from the internal edge
- UL Listed for 2-Hour Fire Rated Doors
- European Standard EN1634-1 for 120-Minute Fire Doors
- CE Certified for 200,000 Opening / Closing Cycles
- 5 Year Warranty
Specifications
- Dimensions
- 6 5/16” x 1 ¼”
Product documents
SpecificationsCR3D62 specificationsAccessories3D Hinge Accessories 2025CR3D62_TemplateCR3D62 TemplateCR3D62_Instruction SheetCR3D62 Instruction Sheet webDrilling Template for 3D Hinges_Instruction SheetDrilling Template for 3D Hinges - Instruction Sheet v2Part Numbers3D Invisible Hinges Part Numbers 2025View Catalog3D Invisible Hinges Catalog 2025Handing Chartdoorframehandingchart
