Manufacturer product view. Confirm the selected finish on your quote.
Cal-Royal · Hinges
CR3D51
Model CR3D51
Project pricing by quote
Finish — Satin Brass
5 ⅛" x 1 ³⁄₁₆" (130 x 30 mm)
View manufacturer productFeatures & options
- Zinc Alloy manufactured for oxidation resistance
- Durable galvanized steel covers to conceal the screws
- Used for wood and hollow metal doors
- 100% Made in Italy
- Elegant minimalistic design that is available in US1, US4, US10B, US14, US15, US26, US26D and US28 finishes with no visible screws
- Main Features
- Easy 3D adjusting system
- Easy installation and maintenance free
- Complete reversibility (same slot on the door and the frame)
- Total recessed hinge body (door and frame gap is very small)
- Milling cut up to ¼” (7.5mm) from the internal edge
- European Standard EN1634-2 for 30-Minute Fire Doors
- CE Certified for 200,000 Opening / Closing Cycles
- 5 Year Warranty
Specifications
- Dimensions
- 5 ⅛” x 1 3/16”
Product documents
SpecificationsCR3D51 specificationsAccessories3D Hinge Accessories 2025CR3D51_TemplateCR3D51 TemplateCR3D51_Instruction SheetCR3D51 Instruction Sheet webCR3D51_Dimension LayoutCR3D51 DIM LAY OUTDrilling Template for 3D Hinges - Instruction SheetDrilling Template for 3D Hinges - Instruction Sheet v2Part Numbers3D Invisible Hinges Part Numbers 2025View Catalog3D Invisible Hinges Catalog 2025Handing Chartdoorframehandingchart
