Manufacturer product view. Confirm the selected finish on your quote.
Cal-Royal · Builders Hardware
UNIFB820
Model UNIFB820
Project pricing by quote
Features & options
- UL Listed for (A, B, C, D and E Label) metal fire doors, maximum 8’ in height. Conforms to UL10C and UBC 7-2-1997.
- UL Listed for (B, C, D and E Label) wood composite core fire doors, maximum 8’ in height. Conforms to UL10C and UBC 7-2-1997.
- Fits standard and ANSI preparation for wood doors.
- Fits standard and ANSI preparation for metal doors.
- Override feature prevents damage to doors or frame in case the strike and bolt are not aligned.
- Reversible, non-handed.
- Steel body with stainless steel components, especially designed thermal lock automatically locks inactive door in case of fire.
- Fully automatic — when active door is opened, top and bottom bolts are automatically retracted for easy egress. When active door is closed, ¾” bolt projects into the frame, securing latching of inactive leaf.
- Bolts have ⅝” vertical adjustment without removing door from frame for unusual conditions.
- Available in architectural finishes.
- Packed 2 bolts per box with composite installation template.
