UNIFB930

Features & options

• UL Listed for (A, B, C, D and E Label) metal fire doors, maximum 8’ in height. Conforms to UL10C and UBC 7-2-1997.
• UL Listed for (B, C, D and E Label) wood composite core fire doors, maximum 8’ in height. Conforms to UL10C and UBC 7-2-1997.
• Fits standard and ANSI preparation for wood doors.
• Fits standard and ANSI preparation for metal doors.
• Override feature prevents damage to doors or frame in case the strike and bolt are not aligned.
• Reversible, non-handed.
• Bolts have ⅝” vertical adjustment without removing door from frame for unusual conditions.
• Available in architectural finishes.
• Packed 2 bolts per box with composite installation template.
• Used where a fire-rating application without a bottom bolt is required.
• Auxiliary fire latch, mounted in the door edge, releases under extremely high temperatures to keep the doors in alignment during a fire.
