Manufacturer product view. Confirm the selected finish on your quote.
Cal-Royal · Exit Devices
4400 Series
Model 4400EO36 • 4400EO48
Project pricing by quote
Finish — Satin Chrome
Cross Bar Rim Type
View manufacturer productFeatures & options
- ANSI A156.3, GRADE 2 Standard Duty Rim Type Exit Device
- Lifetime Warranty
- UL listed for Panic (UL 305)
- 4 ½” minimum stile width required for single or double door application using standard 440 strike
- Pull lever, thumb piece and escutcheon trims available
- Optional Mullion
- Architectural plated finishes available
Specifications
- Dimensions
- Touchbar height to finished floor36 ½” (927 mm) at center Latch height to finished floor41” (1041 mm) Touchbar projection Neutral 4 ¾” (121 mm) Depressed 3” (76 mm) Main case 8 ½” x 2 ⅝” x 2” (216 mm x 67 mm x 51 mm) End case 4 ⅞” x 2 ⅛” (124 mm x 54 mm) Cross Bar Length 30” for 36” door, 42” for 48” door 440 Roller Strike 3/4” Latch Bolt Dogging Cross Bar
Product documents
Features & Specification4400 SpecsAccessories4400 AccessoriesTemplate - 4400 Crossbar without TrimTemplate - ESC 4400 Crossbar without Trim 220125Template - 4400 End CaseTemplate-4400-End-Case1Template - 4400 Main caseTemplate-4400-Main-case1Template - ESC 4400 Trim Entry TemplateESC-4400-TRIM-Entry-Template1Template - ESC 4430 Trim Passage TemplateESC-4430-TRIM-Passage-TemplateTemplate - ESC 4440 Trim Dummy TemplateESC-4440-TRIM-Dummy-TemplateTemplate - THP4400 Series, Thumb Piece TrimTemplate-THP4400-Series-Thumb-Piece-Trim Template - THP4400 Main CaseTemplate-THP4400-Main-CaseInstallation Instruction - 4400 Series Panic Rim DeviceInstallation-Instruction-4400-Series-Panic-Rim-Device 1Installation Instructions - 4400 ESC Lever TrimInstallation-Instruction-4400-ESC-Lever-Trim1Installation Instructions [Changing Handing] - 4400 ESC Lever TrimInstallation-Instruction-4400-ESC-Lever-Trim-Changing-Handing1Installation Instructions - THP4400 Series Thumb Piece TrimInstallation-Instructions-THP4400-Series-Thumb-Piece-Trim Part Numbers44-Series PN 04.2025Handing Chartexitdevicehandingselectorchart
