Manufacturer family image. Confirm the selected function, configuration and finish on your quote.
Kwikset · light-commercial
Carson Push Button Lever - Keyed - with Pin & Tumbler
Supplier item 438CNL 11P
Project pricing by quote
Account quote required
Add these choices to your request. Abel will confirm the complete item, selling unit and price.
Finish — Venetian Bronze
Features & options
- For use on exterior doors where keyed entry and security is needed
- Latch is 20 minute fire rated with round corner face
- Meets ADA/ANSI A117.1 requirements
- ANSI/BHMA grade 3 certified
- Latch has adjustable backset 2-3/8" to 2-3/4" to fit all standard door preparations
- Locking mechanism functions by pressing the push button on the interior of the lock
- Meets or exceeds Underwriter Laboratories (UL) testing requirements specified for each product grade or rating
- Fully reversible lever, can be installed on both right handed and left handed doors
- Easily installs in minutes with just a screwdriver
- Lifetime Mechanical, 5 Year Finish
Specifications
- Kwikset Family
- Carson
- Product Type
- Lever
- Style
- Transitional
- SmartKey
- No
- Has Microban?
- Yes
- ANSI Grade
- Grade 3
- Min Door Thickness
- 1-3/8
- Max Door Thickness
- 1-3/4
- Assembled Height
- 2-14/25
- Assembled Width
- 3-4/5
- Assembled Length
- 2-31/100
- Lever Handling
- Reversible
- ADA Compliant
- Yes
- Body Material
- Metal
- Key Quantity Per Pack
- 2
