Shown in Satin Stainless Steel.
Pamex · Electronic Hardware
Electric Strike - 600 Series
Supplier item ES-634FSS
Project pricing by quote
Finish — Satin Stainless Steel
Features & options
- For Rim Type Exit Devices
- Surface mounted, no frame cutting required
- Non-handed & fully reversible
- Horizontal adjustment
- Field reversible for Fail-Safe or Fail-Secure
- Built-in Latch monitoring
- Static strength: 1500 lbs.
- Dynamic strength: 70 ft-lbs.
- Housing Thickness: 3/4” (ES-634F model)
- Dual Voltage (field selectable): - 540mA @ 12VDC - 270mA @ 24VDC
- One year electronic warranty
- Five years finish warranty
- ANSI/BHMA A156.31. Grade 1
- UL 10C, 3 hour fire-rated (fail-secure only)
- UL 1034, Burglary-resistant rated
Specifications
- Static strength
- 1500 lbs.
- Dynamic strength
- 70 ft-lbs.
- Housing Thickness
- 3/4” (ES-634F model)
- Dual Voltage (field selectable)
- - 540mA @ 12VDC - 270mA @ 24VDC
