A7760V & AF7760V Vertical Rod Type Exit Device (ADA)

Specifications

Dimensions

Touch bar height to finished floor 41” (1041 mm) at center Touch bar projection Neutral Depressed 3 ⅝” (92 mm) 2 ⅞” (73 mm) Center case 8 ⅟16” x 2 ¾” x 2 ½” (205 mm x 68 mm x 62 mm) Panic grade top & bottom latch case 3 15/16” x 2 ⅛” x 1 ⅜” (100 mm x 52 mm x 42 mm) Fire grade top latch case 3 15/16” x 2 9/16” x 2 ⅟16” (100 mm x 68 mm x 53 mm) Fire grade bottom latch case 3 15/16” x 2 ⅛” x 1 ⅜” (100 mm x 52 mm x 42 mm) Top and bottom rod length for 36” x 84” doors Top rod 37 ½” (955 mm), bottom rod 35 ⅝” (905 mm) Top and bottom rod length for 48” x 96” doors Top rod 49 ⅝” (1260 mm), bottom rod 35 ⅝” (905 mm) Vertical Rods ½” (13 mm) Round tubing
