98-3PT & F98-3PT Surface Vertical Rod, Three-Point Latching Exit Device

Specifications

Dimensions

Touch bar height to finished floor 41” (1041 mm) at center Touch bar projection Neutral Depressed 2 ⅝” (67 mm) 1 ⅞” (48 mm) Center case 8” x 2 ¾” x 2 ¼” (203 mm x 70 mm x 57 mm) Panic grade top & bottom latch case 4” x 2” x 1 13/16” (102 mm x 51 mm x 46 mm) Fire grade top & bottom latch case 4” x 2” x 1 13/16” (102 mm x 51 mm x 46 mm) Top and bottom rod length for 36” x 84” doors Top rod 37 ⅞” (962 mm), bottom rod 34 ⅞” (886 mm) Top and bottom rod length for 48” x 96” doors Top rod 37 ⅞” + 12” ETR (1267 mm), bottom rod 34 ⅞” (886 mm) Vertical Rods 15/32” (11.9 mm) round tubing
