A6660V & AF6660V Surface Vertical Rod Type Exit Device (ADA)

Specifications

Dimensions

Touch bar height to finished floor 41” (1041 mm) at center Touch bar projection Neutral Depressed 2 ⅝” (67 mm) 1 ⅞” (48 mm) Center case 8 ⅟16” x 2 ¾” x 2 ½” (205 mm x 68 mm x 62 mm) Panic grade top & bottom latch case 4” x 2” x 1 ¾” (102 mm x 51 mm x 44 mm) Fire grade top & bottom latch case 4” x 2” x 1 ¾” (102 mm x 51 mm x 44 mm) Top and bottom rod length for 36” x 84” doors Top rod 37 ½” (953 mm), bottom rod 33 ½” (851 mm) Top and bottom rod length for 48” x 96” doors Top rod 37 ½” + 12” ETR (1257 mm), bottom rod 33 ½” (851 mm) Vertical Rods 15/32” (11.9 mm) round tubing
